CAT-Repeater Basic

Item no. A2300087
no video signal
Module to extend the transmission range between 2 CAT components of a digital matrix switch
Learn more
The form could not be loaded.

CAT-Repeater extension modules

let you extend the transmission range between two CAT components of a digital matrix switch. An expansion module adds 140 meters to the overall transmission distance. You can use up to five expansion modules on one line.

Transmission
  • The transmission distance is up to 140 meters over CAT
Device
  • PowerPack not included in the scope of delivery for Basic variants
Operation
  • The device can be placed between the following components:
    • Two digital matrix switches
    • A computer module (e. g. DVI-CPU) and a digital matrix switch
    • A console module (e. g. DVI-CON) and a digital matrix switch
Device
  • External power pack supplies up to five modules with power via the power loop function
Device
  • External power supply via external 12V power pack or G&D-MultiPower, providing a central and redundant power supply
GeneralProduct group KVM-Add-ons
MaintenanceUpdate via Update Wizard (service interface)
Serviceport settings 115200bps (8/N/1)
HousingMaterial anodised aluminium
Width ca. 105 mm
Height ca. 26 mm
Depth ca. 84 mm
IP protection class IP20
Weight ca. 0.23 kg
Operating conditionsOperating temperature 5 °C to 45 °C
Operating air humidity 20 % to 80 %, non-condensing
Area of application Interior
Maximum operating altitude 3048m above sea level
Storage temperature -10 °C to 60 °C
Storage air humidity 15 % to 80 %, non-condensing
MTBF 250000 h at 25°C
Conformities CE compliant (see downloads)
UKCA compliant (see downloads)
FCC compliant (see manual)
TAA compliant (see downloads)
EAC compliant (see downloads)
RoHS compliant (see downloads)
WEEE (reg. no. DE30763240)
REACH compliant (see downloads)
Power supplyInput voltage 12 VDC
Current consumption 0.3 A
Power consumption idle 1.3 W
Power consumption max. 2.4 W
Heat output idle 1.3 W
Heat output max. 2.4 W
