GPIO-Changer-PS/2 DV-Power incl. PowerPack

Item no. A3130014

Back to last view

Converter for GPIO-Pins of a PS/2 interface to a Phoenix-Contact block

Product variants

Request product now

Add to watchlist Compare product Questions about the product?

Learn more

The form could not be loaded.

The GPIO-Changer-PS/2

is a signal converter, which makes it easy to use the GPIO function of compatible matrix switches and their end devices. GPIO stands for „general purpose input/output“ and refers to the transmission of simple switching states (on/off). Application fields include alarms in control rooms, the automation of critical monitoring states, or the typical "tally light" as on-air signal in broadcasting.

Transmission

Switching states that are applied to the respective PS/2 contacts on the computer side are reproduced accordingly by the system on the receiver module on the user side, and vice versa.

Each PS/2-interface is able to depict two GPIO-switsching states

Device

The signal converter can be used, for example, in the following fields of application:
- Transmission of the signal of an emergency button on the operating side
  (alarms in control rooms)
- Transmission of a switching signal on the computer, which controls an acoustic alarm or a visual signal in the form of a warning light (on-air signalling in broadcast)

PowerPack not included in the scope of delivery for Basic variants

Device

External power pack supplies up to three modules with power via the power loop function

Device

External power supply via external 12V power pack or G&D-MultiPower, providing a central and redundant power supply

General	Product group	KVM-Add-ons
Input options	PS/2 mouse	yes
Input options	PS/2 keyboard	yes
Maintenance	Update via	no update possibility
Housing	Material	anodised aluminium
	Width	ca. 105 mm
	Height	ca. 26 mm
	Depth	ca. 84 mm
	IP protection class	IP20
	Weight	ca. 0.21 kg
Operating conditions	Operating temperature	5 °C to 45 °C
	Operating air humidity	20 % to 80 %, non-condensing
	Area of application	Interior
	Maximum operating altitude	3000m above sea level
	Storage temperature	-20 °C to 55 °C
	Storage air humidity	15 % to 80 %, non-condensing
	MTBF	144000 h at 25°C
	Conformities	CE compliant (see downloads) UKCA compliant (see downloads) FCC compliant (see manual) TAA compliant (see downloads) EAC compliant (see downloads) RoHS compliant (see downloads) WEEE (reg. no. DE30763240) REACH compliant (see downloads)
Power supply	Input voltage	12 VDC
	Current consumption	0.1 A
	Power consumption idle	1 W
	Power consumption max.	1 W
	Heat output idle	1 W
	Heat output max.	1 W

Product comparison

Mark differences Hide same values

Technical data		GPIO-Changer-PS/2 DV-Power Basic Item no. A3130013	selected variant GPIO-Changer-PS/2 DV-Power incl. PowerPack Item no. A3130014	GPIO-Changer-PS/2 Basic Item no. A3130011	GPIO-Changer-PS/2 incl. PowerPack Item no. A3130012

		General	General	General	General
General	Product group	Product group KVM-Add-ons	Product group KVM-Add-ons	Product group KVM-Add-ons	Product group KVM-Add-ons

		Input options	Input options	Input options	Input options
Input options	PS/2 mouse	PS/2 mouse yes	PS/2 mouse yes	PS/2 mouse yes	PS/2 mouse yes
Input options	PS/2 keyboard	PS/2 keyboard yes	PS/2 keyboard yes	PS/2 keyboard yes	PS/2 keyboard yes

		Maintenance	Maintenance	Maintenance	Maintenance
Maintenance	Update via	Update via no update possibility	Update via no update possibility	Update via no update possibility	Update via no update possibility

		Housing	Housing	Housing	Housing
Housing	Material	Material anodised aluminium	Material anodised aluminium	Material anodised aluminium	Material anodised aluminium
	Width	Width ca. 105 mm	Width ca. 105 mm	Width ca. 105 mm	Width ca. 105 mm
	Height	Height ca. 26 mm	Height ca. 26 mm	Height ca. 26 mm	Height ca. 26 mm
	Depth	Depth ca. 84 mm	Depth ca. 84 mm	Depth ca. 84 mm	Depth ca. 84 mm
	IP protection class	IP protection class IP20	IP protection class IP20	IP protection class IP20	IP protection class IP20
	Weight	Weight ca. 0.21 kg	Weight ca. 0.21 kg	Weight ca. 0.20 kg	Weight ca. 0.20 kg

		Operating conditions	Operating conditions	Operating conditions	Operating conditions
Operating conditions	Operating temperature	Operating temperature 5 °C to 45 °C	Operating temperature 5 °C to 45 °C	Operating temperature 5 °C to 45 °C	Operating temperature 5 °C to 45 °C
	Operating air humidity	Operating air humidity 20 % to 80 %, non-condensing	Operating air humidity 20 % to 80 %, non-condensing	Operating air humidity 20 % to 80 %, non-condensing	Operating air humidity 20 % to 80 %, non-condensing
	Area of application	Area of application Interior	Area of application Interior	Area of application Interior	Area of application Interior
	Maximum operating altitude	Maximum operating altitude 3000m above sea level	Maximum operating altitude 3000m above sea level	Maximum operating altitude 3000m above sea level	Maximum operating altitude 3000m above sea level
	Storage temperature	Storage temperature -20 °C to 55 °C	Storage temperature -20 °C to 55 °C	Storage temperature -20 °C to 55 °C	Storage temperature -20 °C to 55 °C
	Storage air humidity	Storage air humidity 15 % to 80 %, non-condensing	Storage air humidity 15 % to 80 %, non-condensing	Storage air humidity 15 % to 80 %, non-condensing	Storage air humidity 15 % to 80 %, non-condensing
	MTBF	MTBF 144000 h at 25°C	MTBF 144000 h at 25°C	MTBF 144000 h at 25°C	MTBF 144000 h at 25°C
	Conformities	Conformities CE compliant (see downloads) UKCA compliant (see downloads) FCC compliant (see manual) TAA compliant (see downloads) EAC compliant (see downloads) RoHS compliant (see downloads) WEEE (reg. no. DE30763240) REACH compliant (see downloads)	Conformities CE compliant (see downloads) UKCA compliant (see downloads) FCC compliant (see manual) TAA compliant (see downloads) EAC compliant (see downloads) RoHS compliant (see downloads) WEEE (reg. no. DE30763240) REACH compliant (see downloads)	Conformities CE compliant (see downloads) UKCA compliant (see downloads) FCC compliant (see manual) TAA compliant (see downloads) EAC compliant (see downloads) RoHS compliant (see downloads) WEEE (reg. no. DE30763240) REACH compliant (see downloads)	Conformities CE compliant (see downloads) UKCA compliant (see downloads) FCC compliant (see manual) TAA compliant (see downloads) EAC compliant (see downloads) RoHS compliant (see downloads) WEEE (reg. no. DE30763240) REACH compliant (see downloads)

		Power supply	Power supply	Power supply	Power supply
Power supply	Input voltage	Input voltage 12 VDC	Input voltage 12 VDC	Input voltage 12 VDC	Input voltage 12 VDC
	Current consumption	Current consumption 0.1 A	Current consumption 0.1 A	Current consumption 0.1 A	Current consumption 0.1 A
	Power consumption idle	Power consumption idle 1 W	Power consumption idle 1 W	Power consumption idle 1 W	Power consumption idle 1 W
	Power consumption max.	Power consumption max. 1 W	Power consumption max. 1 W	Power consumption max. 1 W	Power consumption max. 1 W
	Heat output idle	Heat output idle 1 W	Heat output idle 1 W	Heat output idle 1 W	Heat output idle 1 W
	Heat output max.	Heat output max. 1 W	Heat output max. 1 W	Heat output max. 1 W	Heat output max. 1 W
