| Product group |
Digital Signage
|
| Product Family |
DP1.2-Splitter-2
|
| Power Supply |
no redundancy
|
| Quantity |
2
|
| Format |
DisplayPort 1.2 (LBR, HBR, HBR2, SingleStream-Transport (SST))
|
| Colour depth |
24 bit
|
| Pixel encoding |
RGB 4:4:4 (24 bpp / 8 bpc)
|
| Pixel rate ca. |
0 MPixel/s to 600 MPixel/s
|
| Vertical frequency |
24 Hz to 240 Hz
|
| Horizontal frequency |
25 kHz to 295 kHz
|
| Exemplary resolutions |
4096 × 2160 (60 Hz)
3840 × 2160 (60 Hz)
2560 × 1600 (60 Hz)
2560 × 1440 (144 Hz)
2048 × 2048 (60 Hz)
1920 × 1200 (60 Hz)
1920 × 1080 (240 Hz)
1920 × 1080 (60 Hz)
5120 × 1440 (60 Hz)
5120 × 2160 (50 Hz)
|
| General Notes |
Further VESA and CTA standardised resolutions possible within pixel rate and horizontal/vertical frequency.
|
| Supported industry standards |
Display Data Channel Command Interface (DDC/CI)
|
| Quantity |
2
|
| Format |
DisplayPort 1.2 (LBR, HBR, HBR2, SingleStream-Transport (SST))
|
| Colour depth |
24 bit
|
| Pixel encoding |
RGB 4:4:4 (24 bpp / 8 bpc)
|
| Pixel rate ca. |
0 MPixel/s to 600 MPixel/s
|
| Vertical frequency |
24 Hz to 240 Hz
|
| Horizontal frequency |
25 kHz to 295 kHz
|
| Exemplary resolutions |
4096 × 2160 (60 Hz)
3840 × 2160 (60 Hz)
2560 × 1600 (60 Hz)
2560 × 1440 (144 Hz)
2048 × 2048 (60 Hz)
1920 × 1200 (60 Hz)
1920 × 1080 (240 Hz)
1920 × 1080 (60 Hz)
5120 × 1440 (60 Hz)
5120 × 2160 (50 Hz)
|
| General Notes |
Further VESA and CTA standardised resolutions possible within pixel rate and horizontal/vertical frequency.
|
| Supported industry standards |
Display Data Channel Command Interface (DDC/CI)
Extended Display Identification Data (EDID)
|
| Transmission type |
LPCM (2/4/6/8 channels)
Stereo
|
| Resolutions |
24 bit
20 bit
16 bit
|
| Sampling rate |
up to 32 kHz
up to 44.1 kHz
up to 48 kHz
up to 88.2 kHz
up to 96 kHz
up to 176.4 kHz
up to 192 kHz
|
| Audio support |
Digital Embedded
|
| Transmission type |
Consumer
SPDIF
Stereo
2-channel LPCM
|
| Resolutions |
24 bit
|
| Sampling rate |
up to 48 kHz
up to 96 kHz
up to 192 kHz
|
| Bandwidth |
22 kHz
|
| Audio support |
Digital
|
| Update via |
Update Wizard (service interface)
|
| Serviceport settings |
115200bps (8/N/1)
|
| Material |
anodised aluminium
|
| Width ca. |
105 mm
|
| Height ca. |
26 mm
|
| Depth ca. |
84 mm
|
| IP protection class |
IP20
|
| Weight ca. |
0.2 kg
|
| Operating temperature |
5 °C to 40 °C
|
| Operating air humidity, non-condensing |
20 % to 80 %
|
| Area of application |
Indoor use
|
| Maximum operating altitude above sea level |
3,048 m
|
| Storage temperature |
-10 °C to 55 °C
|
| Storage air humidity, non-condensing |
15 % to 85 %
|
| MTBF |
150,000 h at 25°C
|
| Conformities |
CE compliant (see downloads)
UKCA compliant (see downloads)
FCC compliant (see manual)
TAA compliant (see downloads)
EAC compliant (see downloads)
RoHS compliant (see downloads)
WEEE (reg. no. DE30763240)
REACH compliant (see downloads)
|
| Quantity |
1
|
| Type |
External
|
| Input voltage |
12 VDC
|
| Current consumption |
0.5 A
|
| Power consumption idle |
0.8 W
|
| Power consumption max. |
1.5 W
|
| Heat output idle |
0.8 W
|
| Heat output max. |
1.5 W
|
