MultiPower-2-12V 2x 12V/0.8A

Item no. A4110053

Back to last view

Central power supply for 2 12V devices with max. 0.8A each

Request product now

Add to watchlist Compare product Questions about the product?

Learn more

The form could not be loaded.

This MultiPower

serves as the central power source of G&D devices that require an external power pack (12V). A redundant power supply can be ensured via two external power supply units. The MultiPower is a functional, space-saving and secure solution for applications in server rooms or computer racks.

Device

Central power supply, for example in racks
Enables external monitoring of the device status

Security features

MultiPower-12-HP, MultiPower-12 and MultiPower-6:
- redundant internal power units
24V variant:
- redundant external power supply, 3 pin Phoenix connector
  (PowerPacks not included in the scope of delivery)
MultiPower-2:
- redundant external power supply

Operation features

MultiPower-12-HP:
- Connction of up to twelve 12V devices
  (12 output interfaces supply G&D devices with 12V and max. 1,2A – depends on the devices; with port configuration, up to six G&D devices with 12V and max. 2.4A (high power) can be connected)
- Configuration and update via the multilingual HTML5 web interface “Config Panel 21” (Java-free)
MultiPower-12:
- Connection of up to twelve 12V devices
  (12 output interfaces supply G&D devices with 12V and max. 600mA – depends on the devices)
MultiPower-6:
- Conncetion of up to six 12V devices
  (6 output interfaces supply G&D devices with 12V and max. 1.2A – depends on the devices)
MultiPower-2:
- Conncetion of up to two 12V devices
  (2 output interfaces supply G&D devices with 12V and max. 1.5A – depends on the devices)

General	Product group	Accessories
Maintenance	Update via	no update possibility
Housing	Material	anodised aluminium
	Width	ca. 105 mm
	Height	ca. 26 mm
	Depth	ca. 84 mm
	IP protection class	IP20
	Weight	ca. 0.20 kg
Operating conditions	Operating temperature	5 °C to 45 °C
	Operating air humidity	20 % to 80 %, non-condensing
	Area of application	Interior
	Maximum operating altitude	3048m above sea level
	Storage temperature	-20 °C to 55 °C
	Storage air humidity	15 % to 85 %, non-condensing
	MTBF	100000 h at 25°C
	Conformities	Produktsicherheit 2001/95/EC EAC TR ZU 002/2011 Deklaration EAC TR ZU 004/2011 Deklaration EAC TR ZU 037/2016 Deklaration Elektroaltgeräteentsorgung WEEE 2012/19/EU Stoffverbote RoHS 2011/65/EU EN55032 (CISPR 32) - EMV Emission EMV-Richtlinie 2014/30/EU EN55024 EMV Störfestigkeit EN61000-3-2 - EMV Stromoberwellen EN61000-3-3 - EMV Flicker Niederspannungsrichtlinie 2014/35/EU EN60950 - Safety FCC CFR 47 part 15 subpart B cl. B
Power supply	Input voltage	12 VDC
	Current consumption	3 A
	Power consumption max.	43 W
	Heat output max.	1.2 W
Power supply 2	Input voltage	12 VDC
	Current consumption	3 A
	Power consumption max.	43 W
	Heat output max.	1.2 W
