extends/receives RS232 signals. The system consists of a computer module (transmitter) and a console module (receiver) and uses CAT-x cables to transmit RS232 signals up to 280 m.
| General | Product group |
KVM extenders |
|---|---|---|
| Transmission | Number of transmission channels |
1 |
| Redundant transmission channels |
no redundant KVM transmission | |
| Range |
280 m (AWG22) 260 m (AWG24) 200 m (AWG26) | |
| Medium |
CAT7 CAT6 CAT5e | |
| Serial | Standard |
RS232 |
| Transparent transmission |
yes | |
| Data rate |
max. 115200 bps | |
| Signals |
TxD RxD DTR DSR RTS CTS DCD RI | |
| Maintenance | Update via |
no update possibility |
| Housing | Material |
anodised aluminium |
| Width |
ca. 55 mm | |
| Height |
ca. 24 mm | |
| Depth |
ca. 104 mm | |
| IP protection class |
IP20 | |
| Weight |
ca. 0.12 kg | |
| Operating conditions | Operating temperature |
5 °C to 45 °C |
| Operating air humidity |
20 % to 80 %, non-condensing | |
| Area of application |
Interior | |
| Maximum operating altitude |
3048m above sea level | |
| Storage temperature |
-10 °C to 55 °C | |
| Storage air humidity |
15 % to 85 %, non-condensing | |
| Conformities |
CE compliant (see downloads) UKCA compliant (see downloads) FCC compliant (see manual) TAA compliant (see downloads) EAC compliant (see downloads) RoHS compliant (see downloads) WEEE (reg. no. DE30763240) REACH compliant (see downloads) | |
| Power supply | Input voltage |
5 VDC |
| Current consumption |
0.07 A |
