CAT-RS232-CPU

Item no. A1990006
Back to last view
Dedicatedtwisted pair cable (CAT)RS232
Computer module to extend RS232 signals via CAT cable
Request product now
Add to watchlistCompare productQuestions about the product?
Learn more
Close
The form could not be loaded.

The signal extender system CAT-RS232

extends/receives RS232 signals. The system consists of a computer module (transmitter) and a console module (receiver) and uses CAT-x cables to transmit RS232 signals up to 280 m.

Signals
  • Transparent bidirectional RS232 (max. 115,200 bps)
Transmission
  • The transmission distance is up to 280 meters over CAT
Device
  • External power supply
Warranty
  • A 3-year, free of charge product guarantee
GeneralProduct group KVM extenders
Product Family CAT-RS232-CPU/CON
Power Supply no redundancy
TransmissionNumber of transmission channels 1
Redundant transmission channels no redundant KVM transmission
Range 280 m (AWG22)
260 m (AWG24)
200 m (AWG26)
Medium CAT7
CAT6
CAT5e
SerialStandard RS232
Transparent transmission yes
Data rate max. 115,200 bps
Signals TxD
RxD
DTR
DSR
RTS
CTS
DCD
RI
MaintenanceUpdate via no update possibility
HousingMaterial anodised aluminium
Width ca. 55 mm
Height ca. 24 mm
Depth ca. 104 mm
IP protection class IP20
Weight ca. 0.12 kg
Operating conditionsOperating temperature 5 °C to 45 °C
Operating air humidity, non-condensing 20 % to 80 %
Area of application Indoor use
Maximum operating altitude above sea level 3,048 m
Storage temperature -10 °C to 55 °C
Storage air humidity, non-condensing 15 % to 85 %
Conformities CE compliant (see downloads)
UKCA compliant (see downloads)
FCC compliant (see manual)
TAA compliant (see downloads)
EAC compliant (see downloads)
RoHS compliant (see downloads)
WEEE (reg. no. DE30763240)
REACH compliant (see downloads)
Power supplyQuantity 1
Type External
Input voltage 5 VDC
Current consumption 0.07 A
