for transmitting analog and digital (SPDIF) stereo audio signals over distances of up to 10,000 m. Such a single signal extender system consists of a computer module (transmitter) and console module (receiver). The product can be used flexibly as a transmitter or receiver. Two devices are required for a complete system. Transmission takes place via a CAT or fiber connection.
| General | Product group |
KVM extenders |
|---|---|---|
| Number of sources |
1 | |
| Transmission | Number of transmission channels |
1 |
| Redundant transmission channels |
no redundant KVM transmission | |
| Range |
140 m (AWG22) 100 m (AWG24) 80 m (AWG26) | |
| Medium |
CAT5e CAT6 CAT7 | |
| Data rate |
1 Gbit/s | |
| Audio | Transmission type |
Bidirectional Stereo |
| Resolutions |
24 bit digital | |
| Sampling rate |
up to 192 kHz | |
| Bandwidth |
22 kHz | |
| Audio support |
Analog | |
| Audio 2 | Transmission type |
Consumer SPDIF Stereo 2-channel LPCM |
| Resolutions |
24 bit | |
| Sampling rate |
48 kHz 96 kHz 192 kHz | |
| Bandwidth |
22 kHz | |
| Audio support |
Digital | |
| Maintenance | Update via |
Update Wizard (service interface) |
| Serviceport settings |
115200bps (8/N/1) | |
| Housing | Material |
anodised aluminium |
| Width |
ca. 105 mm | |
| Height |
ca. 26 mm | |
| Depth |
ca. 84 mm | |
| IP protection class |
IP20 | |
| Weight |
ca. 0.20 kg | |
| Operating conditions | Operating temperature |
5 °C to 45 °C |
| Operating air humidity |
20 % to 80 %, non-condensing | |
| Area of application |
Interior | |
| Maximum operating altitude |
3048m above sea level | |
| Storage temperature |
-10 °C to 55 °C | |
| Storage air humidity |
15 % to 80 %, non-condensing | |
| MTBF |
300000 h at 25°C | |
| Conformities |
CE compliant (see downloads) UKCA compliant (see downloads) FCC compliant (see manual) TAA compliant (see downloads) EAC compliant (see downloads) RoHS compliant (see downloads) WEEE (reg. no. DE30763240) REACH compliant (see downloads) | |
| Power supply | Input voltage |
12 VDC |
| Current consumption |
0.3 A | |
| Power consumption idle |
1.68 W | |
| Power consumption max. |
2.22 W | |
| Heat output idle |
1.68 W | |
| Heat output max. |
2.22 W |
